Marine Cast Iron Screw Down Check Angle Valve JIS F7354 5K
  |
| Dimensions |
|
Code |
module |
Face to Face(L) |
Flange dia.(D) |
Pitch(C) |
Hole(n×d) |
Weight |
| |
|
mm |
mm |
mm |
mm |
Kgs |
|
750216 |
F7306 5K50 |
100 |
130 |
105 |
4×D15 |
12.9 |
|
750217 |
F7306 5K65 |
115 |
155 |
130 |
4×D15 |
18.2 |
|
750218 |
F7306 5K80 |
130 |
180 |
145 |
4×D19 |
23.4 |
|
750219 |
F7306 5K100 |
150 |
200 |
165 |
8×D19 |
33.7 |
|
750220 |
F7306 5K125 |
170 |
235 |
200 |
8×D19 |
46.2 |
|
750221 |
F7306 5K150 |
190 |
265 |
230 |
8×D19 |
63.4 |
|
750222 |
F7306 5K200 |
220 |
320 |
280 |
8×D23 |
105 |
|
750223 |
F7306 5K250 |
275 |
385 |
345 |
12×D23 |
176 |
|
750224 |
F7306 5K300 |
310 |
430 |
390 |
12×D23 |
243 |
|
750225 |
F7306 5K350 |
360 |
480 |
435 |
12×D25 |
327 |
